Somke Sensor
It senses smoke concentrations through a labyrinth, combines temperature changes to determine if there is a fire, and sends an alarm through indicator light and high-decibel buzzer.
With a new generation of high-sensitivity labyrinth to further enhance all-round sensitivity.
With a pyramid embossed design, 16 directions smoke indexes maintains consistency and stability
With anti-tamper function, it will alarm when removed.
With intelligent double-checking algorithm, the smoke concentration exceeds thethreshold or the temperature exceeds 65°C it will alarm,
With Wi-Fi communication protocol, you can directly connect to the platform without a gateway, and push warning message to the App in the mobile phone in the first time.
Datasheet
Specifications, brochure and manual for the Somke Sensor.
Features
- Smart smoke alarm to prevent fire from early stage
- New generation of high-sensitivity labyrinth
- Intelligent double-identification algorithm
- Anti-tamper design
- Powered by battery
- 85dB high resolution alarm
- Multi-scene application
Parameters
- Power supply: DC3V, 1 CR123A battery*1pc
- Communication mode: WiFi/Zigbee communication, directly connected to the platform
- Operating temperature: -10℃ ~ +55℃
- Key: one, self-check mute key
- Indicator light: one, red and blue, indicating the working status
- Detection range: 50 square meters
- Alarm sound pressure: 85db@3m
- Support low voltage alarm;
- Support from the wall demolition;
- Shell material: PC+ABS
- Standby time: 3 years(20 triggers per day)
- Installation method: suction top installation
- Working humidity: 5-95%rh
- Other functions: regular self-inspection
- Dimension: 70mm × 70mm × 29mm
Brochure
Open a sheet to view it full size.
