Smart ControlControl Panel
Control Panel S
Price on request
The smart control panel S adopts a 4-inch touch full screen, developed based on the Linux platform, supports the installation of a standard Europe bottom box, can seamlessly replace the switch panel, and integrates Zigbee gateway and Alexa voice service simultaneously. Interact in various ways to help users quickly and conveniently manage smart devices and scenes at home
Datasheet
Specifications, brochure and manual for the Control Panel S.
Features
- Zigbee Gateway: Integrate the Zigbee gateway function, which can replace the Zigbee gateway at home, and has the edge capability of local control
- Alexa Voice Service: Alexa Built-in，Support IoT control and Alexa voice skills
- Device Control: Multi ways of device control like: touch screen, app control and voice control, compatible with most Tuya ecological devices.
- Scene Control: Both screen interaction and voice interaction can trigger scene control in order to meet different needs in life
- Easy Installation: Wire installation, using the standard European standard base to complete the home automation upgrade
- Easy Setup: Scan the code to log in, interact with the app, one-time configuration
Parameters
- CPU: Rockchip RK3308, Linux
- Power: 100~240VAC,50/60Hz
- RAM: 1GB, ROM 8GB
- Screen: 4 inch 480*480 Multi-touch
- Bluetooth: Mesh
- WiFi: 2.4GHz, 802.11b/g/n 150Mbps
- Zigbee: Zigbee 802.15.4 PHY/MAC network protocol stack
- Working voltage：100-240V
- Operating temperature：0-40℃
- Working humidity：5%-90%RH Non-Condensing
- Communication method：Zigbee,Wi-Fi, Bluetooth Mesh
- Function：Built-in Alexa voice service, Multimode Gateway, Smart scene ,One-click execution of preset without frequent openations
- Size: 86x86x10mm (without the base); 86x86x36.6mm (with the base)
Brochure
Open a sheet to view it full size.
